Armacel Ht armaflex 19×22 -rørisol. Max 150°C 7612207121575

Armacell HT ArmaFlex 19×22 Pipe Insulation – Max 150°C (7612207121575)

The Armacell HT ArmaFlex 19×22 is a high-performance elastomeric pipe insulation designed for thermal protection in high-temperature applications. It is ideal for heating, ventilation, air conditioning (HVAC), industrial piping, and solar thermal systems.

---

🔹 Key Features:

• Brand: Armacell HT ArmaFlex
• Insulation Thickness: 19mm
• Pipe Diameter: 22mm (inner diameter)
• Max Operating Temperature: Up to 150°C
• Material: Flexible elastomeric foam (highly durable and heat-resistant)
• UV & Weather Resistant: Suitable for outdoor installations
• Thermal Conductivity (λ): 0.042 W/(m·K) at 40°C – excellent heat retention
• Fire Resistance: Self-extinguishing and low smoke emissions
• Water Vapor Diffusion Resistance: Highly resistant to moisture penetration
• Flexible & Easy to Install: Cuts easily and fits snugly around pipes

---

🔹 Applications:

✔ HVAC & Refrigeration Systems – Reduces heat loss and prevents condensation
✔ Industrial Hot Water & Steam Pipes – Maintains temperature efficiency
✔ Solar Thermal Systems – Protects pipes in high-temperature solar heating setups
✔ Outdoor & High-Temperature Environments – UV-resistant for long-lasting performance

---

🔹 Benefits:

✔ Reduces energy loss – Improves system efficiency and lowers heating costs
✔ Prevents condensation & corrosion – Protects pipes from moisture damage
✔ Long-lasting & weatherproof – Withstands outdoor conditions
✔ Easy to install & cut – Flexible design for various pipe layouts

---

🔹 Installation Notes:

1. Ensure pipes are clean and dry before applying insulation
2. Cut insulation to the required length using a sharp knife
3. Fit the insulation around the pipe, ensuring a snug fit
4. Seal joints and seams using ArmaFlex adhesive for maximum efficiency
5. For outdoor applications, use additional UV protective coating if required

⚠ Tip: For solar heating systems, ensure insulation is properly secured to withstand high temperatures and external weather conditions.

---

🔹 Alternative Sizes & Models:

• HT ArmaFlex 13x22mm – Thinner insulation for smaller spaces
• HT ArmaFlex 25x22mm – Extra-thick insulation for maximum efficiency
• K-Flex ST 19x22mm – Similar high-temp insulation alternative
